Basic Info
Model No.: SCX01-2/3/4
Color: Grey/white/blue Or Customized
Warranty: 12 Months
Packing: Seaworthing Or Customized
Voltage: 380V Or Customized
Model: SCX01/2/3/4
Additional Info
Packaging: Seaworthy packing, wooden box or customized
Productivity: 100 sets/month
Brand: Sunshine CNC
Transportation: Ocean,Land,Air
Place of Origin: Shandong,China
Supply Ability: 100 sets/month
Certificate: ISO9001/CE/SGS
HS Code: 847780
Port: Qingdao,Shanghai,Guangzhou
Product Description
SCX01-2/3/4 Automatic Water Groove Milling Machine for Plastic Profiles:
1) It is specially used for processing various types of drainage channels and pressure balance grooves of
plastic doors and windows;
2) Independent milling feed mechanism, no need for professional maintenance, high quality of milling sink;
3) The length of the milling tank is continuously adjustable within 60mm, and the adaptability is wide;
4) By using the upper machine head separately with the horizontal machine head, it is possible to efficiently
realize the processing of the symmetric hole groove at both ends of one profile.
Technical Data:
|
Model |
SCX01-2 / 3 / 4 |
|
Voltage |
220V/50HZ or customized |
|
Total power |
0.38KW |
|
Working air pressure |
0.5-0.8Mpa |
|
Diameter of milling cutter |
∮4x50/75mm; ∮5x50/75mm; |
|
Rotation speed |
24000r/min |
|
Max. milling depth |
30mm |
|
Milling width |
4-5mm |
|
Milling length |
0-60mm |
|
Machine size |
1950*860*1600mm |
