CNC Steel Iron Plate Deep Hole Drilling Machine

Payment Type: L/C,T/T,Western Union
Incoterm: FOB,CFR,CIF,EXW,FCA
Min. Order: 1 Set/Sets
Delivery Time: 30  Days

Basic Info

Model No.: PMZ Series

OEM/ODM: OEM/ODM Manufauturing

Certificate: CE/ISO9001

CNC Or Not: CNC

Color: Grey/Blue Or Customized

Voltage: 380V/50HZ/3P Or Customized

Cooling Type: Water/air Cooling

PARTS: Internationl Famous Brand

Model: PMZ-16

Additional Info

Packaging: Wooden Pallet/Wooden Boxes/Nude or customized

Productivity: 10 Sets Per Month

Brand: Sunshine CNC

Transportation: Ocean,Land,Air

Place of Origin: Jinan,China

Supply Ability: 10 Sets Per Month

Certificate: ISO9001

HS Code: 84624190/84624100/84623990

Port: Qingdao,Tianjin,Shanghai

Product Description

CNC Steel Iron Plate Deep Hole Drilling Machine:


1) The machine is mainly composed of bed(worktable), gantry, drilling heard,

   Longitudinal slide platform, hydraulic system,cooling system and chip-conveyor.


2) The gantry moves while the bed is fixed. Workpieces are clamped by the hydraulic

    Clamps which can easily controlled by foot-switch,small workpieces can clamped

    Four groups together on the corners of worktable so as to reduce the preparation

    Period of production and improve the efficiency significantly.


       Model

     PMZ-16

PMZ-2016

Max. size of work-piece(mm)

    1650*1000

   2000*1600

Max. thickness of work-piece(mm)

       80

      100

Max. drilling diameter

      ∮50

     ∮50

Principle Axis

Quick change chuck

Morse taper hole 4# 3# 2#

Morse taper hole 4# 3# 2#

Rotate speed(r/min)

120-150

Stepless speed regulation

120-150

Stepless speed regulation

Feeding stroke(mm)

        180

        180

Motor power (KW)

        5.5

5.5

Feeding mode

     Hydraulic

      Hydraulic

Hydraulic

Clamp

Clamping thickness

     15-80mm

     35-100mm

Tongs number

       12

      12

Clamping force(KN)

       7.5

      7.5

Clamping switch

    Foot switch

Foot switch

Motor Power

Servo Motor (KW)

     1.0/1.0

     1.5/1.5

Hydraulic motor(KW)

       2.2

       2.2

Cooling motor(KW)

      0.25

      0.25




steel drilling (1)

Sunshine Cnc 1


Remarks

Pkg: Seaworthy packing or customized

Terms: FOB/CIF/CFR/EXW

From Qingdao, China To_______,

Delivery Time: During 30 Days After We Receive Your First Payment

Payment: Telex Transfer (T/T), 30% Be Paid After Confirming The Order and

                The rest 70% is effected while delivering the goods

Trademark:



Guarantee & Aftersales service:

1)Guarantee the complete machine for 18 months, except the consumable parts.

2) 24hour technical support by email or calling.

3) User-friendly English manual for machine using and maintaining.



Contact person: Ms.Sailing He

Mobile: +86 18005318120 (Wechat)

Whatsapp: +86 13361033782

Skype: judy.he74
