YBJ Series CNC Plate Processing Center

Payment Type: L/C,T/T,Western Union
Incoterm: FOB,CFR,CIF,EXW,FCA
Min. Order: 1 Set/Sets
Delivery Time: 30  Days

Basic Info

Model No.: YBJ Series

OEM/ODM: OEM/ODM Manufauturing

Certificate: CE/ISO9001

Color: Grey/Blue Or Customized

Voltage: 380V/50HZ/3P Or Customized

Cooling Type: Water/air Cooling

PARTS: Internationl Famous Brand

Warranty :: 12 Months

Condition:: New

Model: YBJ-6

Additional Info

Packaging: Wooden Pallet/Wooden Boxes/Nude or customized

Productivity: 10 Sets Per Month

Brand: Sunshine CNC

Transportation: Ocean,Land,Air

Place of Origin: Jinan,China

Supply Ability: 10 Sets Per Month

Certificate: ISO9001

HS Code: 84624190/84624100/84623990

Port: Qingdao,Tianjin,Shanghai

Product Description

YBJ Series CNC Plate Processing Center

This machine is used for producing the iron tower in electric power, communication

and punching metal parts in automobile and other industries.


Machine`s Features:

1) This machine is a total of six modules (according to user needs can adopt liner die

     arrangement or double row type die arrangement),it can carry on multi-specification,

  multi-aperture punching process, it`s mould is removed and installed conveniently, its

     positioning is accurate, greatly shorten the work stoppage time and tooling adjustment

     time, improve work efficiency;

2) The machine is equipped with a two-spindle CNC feeding table. The work-piece can

     be accurately positioned in any position in the working area to complete the punching

     function;

3) The clamping of he work-piece has the origin location and relocation function, for the

     work-piece of the irregular polygon, the origin location is accurate, convenient and accurate.

     The machining accuracy of the single piece and the interchangeability of the same work-piece

     are guaranteed. For super-long work-piece, the punch hole can be carried out in the middle

     of he machining process;

4) The machine adopts C-type double plate steel plate welding structure, which is rigid, small in size,

     light in weight and large in operating space;

5) The machine has a independent hydraulic power system and electrical numerical control system,

     which adopts centralized central control, and has automatic lubricating device, simple structure,

     easy to use and maintenance.


Technical Data:

Item Name

Numerical Value

 Notes

Punching force(KN)

     1200

Thickness of plate punching(mm)

     4-20

Max. size of work-piece(mm)

   2000*1000

20mm;Q345

Max. dia. of punching hole(mm)

    ∮25.5

Min. distance from hole to edge(mm)

      25

Numbers of die

      6

Diameter 25.5mm

Processing precision

Accordance with GB/T2694



YBJ Plate punching machine

punching machine  punching hole

Punching parts

company name


Jinan XingTian Sunshine CNC Machine Co.,Ltd. is Leading Manufacturer


of  CNC Steel Plate Drilling Machine,CNC Steel Drilling Machine,CNC

Plate Drilling Machine,CNC Drilling Machine in China,having been exporting

to Russia; Ukraine; KSA; UAE;Egypt; Morocco; Kenya; Ethiopia; South

Africa; India; Sri Lanka; Pakistan; Bangladesh;Myanmar; Thailand; Indonesia;

Malaysia;Australia; Brazil; Mexico; South Korea etc. for more than 10 years.



Remarks:

Pkg: Seaworthy packing or customized

Terms: FOB/CIF/CFR/EXW

From Qingdao, China To_______,

Delivery Time: During 30 Days After We Receive Your First Payment

Payment: Telex Transfer (T/T), 30% Be Paid After Confirming The Order and

                The rest 70% is effected while delivering the goods

Trademark:



Guarantee & Aftersales service:

1)Guarantee the complete machine for 18 months, except the consumable parts.

2) 24hour technical support by email or calling.

3) User-friendly English manual for machine using and maintaining.
